Precision Thread Plug Gauge Set – Metric & Imperial,Alloy Steel Construction for Thread Inspection
- Accuracy grade 6H(optional grade 5H, 6G,7H)
- Large sizes are available upon request
- Standard Din13 or ISO 1502-96
- Double ends with GO and NO GO
- Thread Plug Gauge Set
- Metric & Imperial
- Hardened Alloy Steel for Precision Thread Inspection
Parameter:
| Model No. | Size | Pitch | Model No. | Size | Pitch | |
| 1002-002 | M2.0 | 0.40 | 1002-042 | M42.0 | 4.00 | |
| 1002-0022 | M2.2 | 0.45 | 1002-045 | M45.0 | 4.00 | |
| 1002-0025 | M2.5 | 0.45 | 1002-048 | M48.0 | 4.00 | |
| 1002-003 | M3.0 | 0.50 | 1002-052 | M52.0 | 4.00 | |
| 1002-0035 | M3.5 | 0.60 | 1002-056 | M56.0 | 5.50 | |
| 1002-004 | M4.0 | 0.70 | 1002-060 | M60.0 | 5.5 | |
| 1002-005 | M5.0 | 0.80 | 1002-064 | M64.0 | 6.00 | |
| 1002-006 | M6.0 | 1.00 | 1002-068 | M68.0 | 6.00 | |
| 1002-008 | M8.0 | 1.25 | 1002-072 | M72.0 | 6.00 | |
| 1002-010 | M10.0 | 1.5 | 1002-076 | M76.0 | 6.00 | |
| 1002-012 | M12.0 | 1.75 | 1002-080 | M80.0 | 6.00 | |
| 1002-014 | M14.0 | 2.00 | 1002-085 | M85.0 | 6.00 | |
| 1002-016 | M16.0 | 2.00 | 1002-090 | M90.0 | 6.00 | |
| 1002-018 | M18.0 | 2.50 | 1002-095 | M95.0 | Â 6.00 | |
| 1002-020 | M20.0 | 2.50 | 1002-100 | M100.0 | 6.00 | |
| 1002-022 | M22.0 | 2.5 | 1002-105 | M105.0 | 6.00 | |
| 1002-024 | M24.0 | 3.00 | 1002-110 | M110.0 | 6.00 | |
| 1002-027 | M27.0 | 3.00 | 1002-115 | M115.0 | 6.00 | |
| 1002-030 | M30.0 | 3.50 | 1002-120 | M120.0 | 6.00 | |
| 1002-033 | M33.0 | 3.5 | 1002-125 | M125.0 | 6.00 | |
| 1002-036 | M36.0 | 4.00 | 1002-130 | M130.0 | 6.00 | |
| 1002-039 | M39.0 | 4.00 | 1002-140 | M140.0 | 6.00 |
Product Description
Professional Thread Plug Gauge Set – Precision Thread Measurement for Metric & Imperial Applications
Our premium thread plug gauge set provides accurate and reliable thread inspection for various applications including machine tools, manufacturing, and quality control. Manufactured from hardened alloy steel with a durable construction, this 44-piece set offers both metric and imperial sizing compatibility, making it ideal for inspecting thread diameters in low, medium, and high carbon steel materials.
Key Features & Benefits:
• Complete 44-Piece Set – Comprehensive range covering most common bolt sizes and thread types
• Dual Dimension Compatibility – Works with both metric and imperial thread measurements
• Premium Alloy Steel Construction – Hardened material ensures durability and long service life
• Precision Engineering – Accurate thread form and pitch for reliable go/no-go testing
• User-Friendly Design – Loop handle design allows easy handling and precise measurements
• Versatile Application – Suitable for various steel grades and thread diameters
• Quality Assurance – Ideal for machine shops, manufacturing, and quality control departments
Technical Specifications:
• Set Configuration: 44-piece comprehensive set
• Thread Compatibility: Metric and Imperial sizes
• Material: Hardened Alloy Steel
• Design: Loop handle for easy operation
• Application: Thread diameter measurement and inspection
• Finish: Black oxide coating (default)
• Standards: Meets industrial thread measurement standards
Ideal Applications:
Machine tool maintenance and repair
Manufacturing quality control
Automotive and aerospace industries
Mechanical workshops and tool rooms
Production line inspection
Maintenance and repair facilities
Why Choose Our Thread Plug Gauge Set?
This professional-grade thread plug gauge set offers exceptional versatility and precision for all your thread measurement needs. The complete configuration covers most industrial applications, while the hardened alloy steel construction ensures long-term durability. The loop handle design provides comfortable operation, and the dual dimension compatibility makes it suitable for both metric and imperial measurement systems.
[Request Catalog] for complete size specifications or [Contact Us] for custom set configurations and volume pricing.
