Digital Optical Profile Projector CPJ-3000 Series – 2D Measurement Machine with High Accuracy for Metal Parts Inspection
- CPJ-3000/3000Z digital profile projector offers precise non-contact 2D measurement with excellent optical clarity.
- Compact in structure, simple and beautifulin appearance,economicalandpracticaland go0creliability,CPJ-3000/3000Z series digital profileprojector is widely used in the field ofmachinery.electronics,tooling,instrument and timepiece, etcIt can be used efficiently in both direct measuringand comparative measuring, such as measuring ofstamping parts, wheel gears, screws, and cutters, etc.
Product Description:
Digital Optical Profile Projector CPJ-3000 Series
The CPJ-3000 Series digital optical profile projector represents the perfect integration of optics, mechanics, and electronics in precision measurement technology. This compact yet powerful 2D measurement system provides clear, accurate imaging with both inverted and upright projection capabilities, making it ideal for various industrial measurement applications.
Key Features
-
High-Precision Optics: Superior lens system delivers sharp, accurate magnified images with minimal distortion
-
Dual Imaging Modes: Switch between upright and inverted imaging based on measurement requirements
-
Digital Measurement: Precise digital readout system for accurate dimensional analysis
-
Versatile Application: Suitable for contours, angles, radii, and surface feature measurement
-
Comparative Analysis: Direct and comparative measurement capabilities for quality control
-
Robust Construction: Stable bench-top design with vibration resistance for reliable operation
-
User-Friendly Operation: Intuitive controls suitable for both experienced and novice operators
Technical Specifications
-
Model Series: CPJ-3000/3000Z
-
Projection Mode: Upright and inverted imaging
-
Measurement Accuracy: <0.08% contour measurement error under transmitted illumination
-
Magnification Range: [Include specific magnification options based on actual specs]
-
Working Stage: [Include stage size and travel range]
-
Illumination: Transmitted and surface illumination options
-
Digital Readout: High-resolution display with multiple measurement functions
-
Applications: Suitable for metals, plastics, electronic components, and precision parts
Applications
-
Quality Control: Inspection of stamped parts, gears, and precision components
-
Tooling Industry: Measurement of cutting tools, molds, and fixtures
-
Electronics: Micro-component inspection and PCB analysis
-
Watchmaking: Precision timepiece component measurement
-
Automotive: Small part inspection and reverse engineering
-
Research & Education: Laboratory measurements and technical training
-
Aerospace: Precision component verification and documentation
Why Choose Our Profile Projector?
The CPJ-3000 Series profile projector combines German optical precision with modern digital technology, offering exceptional measurement capabilities at an economical price point. Its versatile design accommodates both simple comparative measurements and complex dimensional analysis, making it an invaluable tool for manufacturing quality control, research institutions, and educational facilities. With excellent reliability and straightforward operation, this system provides professional-grade measurement performance for various industrial applications.
[Request Catalog] for complete size specifications or [Contact Us] for custom set configurations and volume pricing.
