Precision Digital Height Gauge – Professional Grade Stainless Steel Vernier Height Caliper with 0.01mm Resolution (300mm to 2000mm Range)
- Data output(Professional Digital Height Gauge )
- Presetting
- Chrome-plated steel construction,Carbide-tipped scriber
- Fine adjustment carriage to fed the slider finely,Complies with GB/T1214.3 standards.
Product Description:
Our Precision Digital Height Gauge is a professional-grade measuring instrument manufactured in compliance with GB/T1214.3 and JB/T5609 standards. Crafted from premium quality steel with chrome-plated surfaces and carbide-tipped jaws, this digital height gauge delivers exceptional measurement accuracy and durability. With resolution of 0.01mm and multiple measuring ranges up to 2000mm, it is ideal for precision measurement applications in manufacturing, quality control, and industrial environments.
Key Features
-
Premium Construction: Made from high-quality steel with chrome-plated surfaces for corrosion resistance
-
Carbide-Tipped Jaws: Ensures extended durability and wear resistance
-
High-Precision Measurement: 0.01mm resolution for accurate dimensional measurement
-
Digital LCD Display: Clear readout for easy measurement reading
-
Wide Range Selection: Available from 300mm to 2000mm (12″ to 80″) measuring capacity
-
Standard Compliance: Manufactured according to GB/T1214.3 and JB/T5609 standards
-
Customization Available: Special requirements can be accommodated upon request
Technical Specifications
| Model Number | Measurement Range | Resolution | Permissible Error |
|---|---|---|---|
| H-131-103GA | 0-300mm/12″ | 0.01mm | ±0.04mm |
| H-131-105GA | 0-500mm/20″ | 0.01mm | ±0.05mm |
| H-131-106GA | 0-600mm/24″ | 0.01mm | ±0.05mm |
| H-131-110G | 0-1000mm/40″ | 0.01mm | ±0.07mm |
| H-131-115G | 0-1500mm/60″ | 0.01mm | ±0.11mm |
| H-131-120G | 0-2000mm/80″ | 0.01mm | ±0.14mm |
Applications
-
Precision height measurement in manufacturing and machining
-
Quality control inspection and verification processes
-
Tool and die making applications
-
Mechanical engineering and industrial maintenance
-
Research and development laboratories
-
Educational and training institutions
Quality Assurance
Each digital height gauge undergoes strict quality control procedures to ensure measurement accuracy and reliability. The chrome-plated surface provides excellent corrosion resistance, while the carbide-tipped measuring jaws ensure long-lasting performance even in demanding industrial environments.
Why Choose Our Digital Height Gauge?
Our Professional Digital Height Gauge combines advanced manufacturing technology with robust materials to deliver exceptional measurement performance. The compliance with international standards ensures reliability, while the wide range of sizes makes it suitable for various industrial applications. Custom solutions are available to meet specific measurement requirements.
[Request Catalog] for complete size specifications or [Contact Us] for custom set configurations and volume pricing.
